BongshaiSteel-101
Affordable Heavy-Duty Steel Structure Factory Building
Model Code: BongshaiSteel-101
Starting from Tk 650 per sq ft Final price depends on size, site and finish — ask for an exact quote.
Bongshai steel building is offering a customized design. All framing is made of built-up section from MS steel plate. Built-up column, rafter are main frame and purlin, girt, bracing is secondary frame. Column is connected with concrete column by anchor bolt. All members are connected by high-strength bolts. Parameter of the Building Building span 10 m ~ 40 m Length 25 m ~ 300 m Bay spacing 6 m, 7.5 m, 9 m & 10 m Height 4 m ~ 10 m
Affordable Heavy-Duty Steel Structure Factory BuildingSteel Structure Factory · Bongshai Steel
01Key attributes
- Model number
- BongshaiSteel-101
- Product type
- Steel Structure Factory
- Brand name
- Bongshai Steel
- Place of origin
- Dhaka, Bangladesh
- Design Standard
- AISC, AISI, BSI
- Load Combination
- MBMA, IBC
- Material
- ASTM, BSI, JIS
- Fabrication Standard
- AWS
- Construction Standard
- BSI
- Anchor Bolt
- ASTM A36, Grade 4.6, yield strength 250 MPa
- Built-up steel (main frame)
- ASTM Grade 50, yield strength 344 MPa
- Secondary frame (purlin, girt)
- ASTM Grade 50, yield strength 344 MPa
- Rod bracing & sag rod
- ASTM A36, Grade 4.6, yield strength 250 MPa
- High-strength bolt
- ASTM A325, Grade 8.8
- Mild steel bolt (MSB)
- ASTM A36, Grade 4.6
- Fastener
- Improved heavy-duty hex-head self-tapping screws with neoprene washer
- Translucent sheet for skylight
- 2 mm thick fiberglass profile sheets made of UV-resistant resin
- Roofing sheet
- Thickness 0.46 mm color-coated steel sheet
What are the engineering specifications of BongshaiSteel-101?
Structural Design and Load Capacity
The Affordable Heavy-Duty Steel Structure Factory Building (BongshaiSteel-101) is engineered by Bongshai Steel's in-house structural engineers to withstand high wind velocity, seismic forces, and heavy dead/live loads. All primary framing members are fabricated from certified structural grade steel, pre-drilled, pre-punched, and precision-cut for rapid on-site bolted assembly.
Surface Treatment and Corrosion Protection
Steel components are sandblasted and finished with an epoxy anti-corrosion coating in the Bongshai Steel factory before dispatch, for service in coastal and demanding industrial environments.
How to order or request an official quote for BongshaiSteel-101?
Because every pre-engineered building is custom engineered to client site dimensions, soil conditions, and eave heights, the price above is a starting figure only. Submit your required square footage and site location below or reach out via WhatsApp at +8801789-949060 to receive a comprehensive technical proposal and cost estimate within 24 hours.
Request Official Quote for BongshaiSteel-101
Please provide your project specifications to receive an official engineering estimate.
Related Steel Structure Factory Models
BongshaiSteel-103
Low-cost Steel Structure Godown Building
Bongshai steel building is offering a customized design. All framing is made of built-up section from MS steel plate. Built-up column, rafter are main frame and purlin, girt, bracing is secondary frame. Column is connected with concrete column by anchor bolt. All members are connected by high-strength bolts. Parameter of the Building Building span 25m ~ 300m Length 30m ~ 300m Bay spacing 7.5m, 9m & 10m Height 6m ~ 10m
Questions about this building
What sizes can a steel structure factory building be?
How is the steel frame built?
Which design standards do you follow?
What roof sheeting and skylights are used?
Is every building designed to order?
Model BongshaiSteel-101 (Affordable Heavy-Duty Steel Structure Factory Building) is a certified pre-engineered steel structure factory manufactured in Dhaka, Bangladesh by Bongshai Steel. Engineered to AISC 360, Eurocode 3, and BNBC 2020 standards, it is export-ready worldwide with custom project pricing.
