Model BH-MB-201 (Glass Certain Steel Building Super Market) is a certified pre-engineered super market manufactured in Dhaka, Bangladesh by Bongshai Steel. Engineered to AISC 360, Eurocode 3, and BNBC 2020 standards, it is export-ready worldwide with custom project pricing.
Glass Certain Steel Building Super Market
Model Code: BH-MB-201
Starting from Tk 3,200 per sq ft Final price depends on size, site and finish — ask for an exact quote.
Pre-Engineered steel building is a customizes design. All framing is made of built-up section from MS steel plate. Built up column, rafter, are main frame. Column is connected with concrete column by Anchor bolt. Precast reinforcement cement concrete panel has been used as typical floor over the steel sub beam. Glass and concrete panel use as vertical wall. Scope of work of the project 1. Reinforcement cement concrete foundation 2. Grade beam, grade beam and grade floor 3. Structural steel use as main frame 4. All structural members are bolted and welded 5. Anti corrosive and epoxy paint 6. Typical floor 7. Concrete wall with plaster 8. Cartain glass wall 9. Wall paint 10. Floor tiles 11. Standard electrification 12. Stair and railing
Glass Certain Steel Building Super MarketSuper Market · Bongshai Steel
01Key attributes
- Model number
- BH-MB-201
- Product type
- Super Market
- Brand name
- Bongshai Steel
- Place of origin
- Dhaka, Bangladesh
- Design Standard:
- AISC, AISI, BSI
- Load Combination:
- MBMA, IBC,
- Material:
- ASTM, BSI, JIS
- Fabrication Standard:
- AWI
- Construction Standard:
- BSI
- Anchor Bolt
- ASTM-A36, Grade-4.6, Yield strength 275 Mpa
- Build up steel (Main frame)
- ASTM, Grade-50, Yield strength 344 Mpa
- High strength bolt
- ASTM-A325, Grade-8.8
- Mild steel bolt (MSB)
- ASTM-A36, Grade-4.6,
What are the engineering specifications of Glass Certain Steel Building Super Market (BH-MB-201)?
Structural Design and Load Capacity
The Glass Certain Steel Building Super Market (BH-MB-201) is engineered by Bongshai Steel's in-house structural engineers to withstand high wind velocity, seismic forces, and heavy dead/live loads. All primary framing members are fabricated from certified structural grade steel, pre-drilled, pre-punched, and precision-cut for rapid on-site bolted assembly.
Surface Treatment and Corrosion Protection
Steel components are sandblasted and finished with an epoxy anti-corrosion coating in the Bongshai Steel factory before dispatch, for service in coastal and demanding industrial environments.
How to order or request an official quote for BH-MB-201?
Because every pre-engineered building is custom engineered to client site dimensions, soil conditions, and eave heights, the price above is a starting figure only. Submit your required square footage and site location below or reach out via WhatsApp at +8801789-949060 to receive a comprehensive technical proposal and cost estimate within 24 hours.
Request Official Quote for BH-MB-201
Please provide your project specifications to receive an official engineering estimate.
